Stake Semi-Trailer Cargo Fence Truck Semi Trailer
2 year ago
**Modern design:Double-Groove vertical van, light-weight I beam, arched form longitudinal beams, that make the trailers
Structure super strong and superlight;
**Sound Adaptability:Passed the special processing, the overall frames of the traielrs can stand the actual test of various
Road conditions.
**Superior Material selection:The raw materials are bought from top 5 Steel Mills, and all of other parts are all from top
Suppliers also, like Triangle tyres, Jost landing gear, WEBCO relay valve, we have strict selection requirement for vendors.
**Top configurations:Ensure every trailers with high configurations to decrease the maintaince for clients, and improve the
Trailers with longer service time
|
Type |
Stake Semi-Trailer Cargo Fence Truck Semi Trailer |
|
Total Length |
Approx 12,500 mm |
|
Total Width |
Approx 2,500 mm (including mud guard) |
|
Total Height |
Approx 3,850mm, adjustable according to the request |
|
King Pin Location |
Approx 972mm from the front face of the front bolster |
|
Wheelbase |
Approx 5,110mm+1310mm+1310mm |
|
Landing Gear location |
2,420mm behind the king pin location |
|
Fifth wheel (King Pin) Height |
Approx 1,350mm with the chassis level |
|
Capacity |
60 tons |
|
Tare Weight |
Approx 8,100 kg (Tolerance 0~-4%) |
|
Max. Payload |
Approx 60,000 |
|
Gross Vehicle Weight |
Approx 68,100 kg |
|
Main Beam |
High strength low alloy steel (700 MPa) is used for welded I-beam and (345MPa) is used for welded fabricated parts. Top 14mm, middle 10mm, bottom 16mm. |
|
Sidewall Dimension |
12500x2500x2400(Board 800+ Fence 1600)mm, Floor 3mm, side 1.5mm, adjustable according to request. |
|
Kingpin |
2” or 3.5’’ Brand: JOST. Made in China. |
|
Landing Gear |
Jost or Goldstone, Lifting capacity 30T and static load 80T. |
|
Suspension |
American type mechanical spring suspension, the leaf spring is 8pcs. |
|
Axles |
3x13T, Fuwa, BPW, or Chinese famous brand. |
|
Rims |
9.0-22.5，12 pieces. 10 holes Steel rim, Made in China. |
|
Tires |
315/80R22.5, 12pieces. China First-level Brand, Made in China. |
|
Brake System |
Dual air brake system, WABCO or Haldex relay valve, none ABS brake system. |
|
Brake chamber |
Type 30/30 on the rear two axles, Type 30 on the first axle. |
|
Electrical System |
24 volt lighting system, 7-way receptacle, ISO standard. |
|
Spare tire carrier |
One set spare tire carrier |
|
Side guard |
None |
|
Tool Box |
One |
|
Reflector tape |
Side yellow color and rear red color reflector tap |
|
Mudguard |
Mudguard on top of tire. |
|
Painting & Logo |
As client ‘s request. |
