HT-LongStroke-5-Detail

Features

Careful Material Selection
1. Use round carbon steel as the cylinder material
2. Select sensor components of internationally famous brands.
3. Key components are made of high-quality materials and processed with vacuum heat treatment or surface treatment (including coating, azotizing, oxidation)
4. Select branded bearings and gears to achieve the best mechanical performance in mechanical structure
5. Select high-quality grease to minimize friction, which enables the drive efficiency to reach up to 90%.
High Reliability
Multiple, multiple security measures
Wide Thrust Range
Select famous branded planetary roller screws, and lead screws which are made of high-quality materials for our electric cylinders in order to reach double the theoretical rated push-pull force.
Complete Testing
Professional and detailed factory testing: appearance, stroke, noise decibel.
Long Life
Run over a distance of 100,000km
Refined Design and Processing
1. The connection between the screw nut and the piston rod is rigid
2. Snap fastener will be required to locate the part in its fixed position to avoid assembly errors that affect mechanical properties.
3. All screw threads are coated with screw locking adhesive after commissioning to ensure the equipment is stable and trouble-free.
4. Adopt domestic planetary roller screw and bearing products, light load output, high-cost performance
5. All heavy-duty cylinders use sliding key guides. (The square cylinders are using guided rod)
Wide Selection of Motors
Can choose AC motor, DC motor, stepper motor, servo motor.
Excellent Service
1. Each DGR Planetary Roller Electric Cylinder is backed by a lifelong tracking service to ensure it can be used normally over its life cycle. (including handling product failure, providing spare parts and technical support)
2. DGR High Precision Electric Cylinder can be custom engineered for customer's particular application
3. All customer requirements will be responded to within 12 hours

Roller screw: The roller screw(Heavy Duty Electric Cylinder) is equipped with a circularly moving roller inside. Compared with the ball screw, the roller has a larger contact area, so its load capacity is usually stronger, but because of the greater friction, the accuracy is relatively low and the speed is also slower. Roller screws are suitable for low speed, heavy load and occasions with low precision requirements.
